    EK 01000
    Home Products Gas Springs EK Series EK 01000

    Search for products: K 19, EF 00170, etc.
    EK 01000
    EK Series
    Model
    EK 01000
    Stroke mm
    13-125
    Fo (daN)
    920
    F1i (daN)
    1459-1656
    F1p (daN)
    1695-2005
    Cylinder DIM
    50
    Piston DIM
    28
    Length mm
    74-298
    Kod
    STR mm
    L mm
    L min mm
    Fo (daN)
    F1i (daN)
    F1p (daN)
    PED
    3D
    EK 01000 013
    13
    74
    61
    920
    1459
    1695
    EK 01000 016
    16
    80
    64
    920
    1480
    1728
    EK 01000 019
    19
    86
    67
    920
    1496
    1753
    EK 01000 025
    25
    98
    73
    920
    1538
    1819
    EK 01000 032
    32
    112
    80
    920
    1563
    1857
    EK 01000 038
    38
    124
    86
    920
    1584
    1891
    EK 01000 050
    50
    148
    98
    920
    1600
    1917
    EK 01000 063
    63
    174
    111
    920
    1617
    1944
    EK 01000 075
    75
    198
    123
    920
    1623
    1953
    EK 01000 080
    80
    208
    128
    920
    1634
    1970
    EK 01000 100
    100
    248
    148
    920
    1643
    1985
    EK 01000 125
    125
    298
    173
    920
    1656
    2005
    Component Parts
    C 050
    C Series
    View Detail
    CB 050
    C Series
    View Detail
    D 050
    D Series
    View Detail
    DK 050
    DK Series
    View Detail
    K 050
    K Series
    View Detail
    KB 050
    K Series
    View Detail
    KC 050
    K Series
    View Detail
    KF 050
    K Series
    View Detail
    TA 050
    T Series
    View Detail
    TD 050
    T Series
    View Detail
    TE 050
    T Series
    View Detail
    TT 050
    T Series
    View Detail
